– 11 –
ENGLISH
4-2-2. Loading the Paper
1 Lift the cover up approx. 3cm. Hold
the cover tilted at this angle, then
pull it toward you to remove it.
2 Cut off the front edge of the roll
paper perpendicularly.
3 Confirm that the power of the printer
is turned on.
4 While observing the direction of the
roll paper, insert the top end of the
paper beneath the paper guide as far as
it will go. If the roll paper is installed,
the top end of the paper automatically
comes out from the paper exit. After
2cm of paper are fed out, the paper
is automatically cut off.
5 Move the paper roll holder in the
direction of the arrow, and insert the
roll so that the holes in the core align
with the axes of the paper roll holder.
Release the paper roll holder to se-
cure the paper.
6 If the paper roll core has not been
properly aligned with the paper roll
holder, the cover cannot to properly
seated until the paper position is
corrected.
Cover
FEED
switch
Fig. 4-12 Removing the cover
Roll paper
Core
Axis
Paper roll holder
Fig. 4-13 Loading the paper
