2-3
Setup and Installation: Mechanical
Wired Ethernet: Power via Power-over-Ethernet
With this installation option, in addition to the MK1000 communicating to the host via a
10Base-T Ethernet cable, the MK1000 also simultaneously receives its power via the same
Ethernet cable.
Note: Power-over-Ethernet should NOT be used in conjunction with an
external power supply connected to the power port on the MK1000
otherwise damage can occur to the MK1000 and/or network.
To install the MK1000, follow the instructions below.
1. Attach the Ethernet cable.
• Connect the Ethernet cable to the LAN port on the MK1000. (See Figure 1-1 on
page 1-3 for port locations.) Ensure the Ethernet cable is terminated according
to the Ethernet Pin-Outs: Obtaining Power via Power-over-Ethernet described
in Table 2-3 and Table 2-4 .
• Plug the other end of the Ethernet cable into the Bias-T (Power-over-Ethernet)
module.
2. Connect a patch cable from the Bias-T (Power-over-Ethernet) module to your host
system’s LAN port.
3. To mount the MK1000, see Mounting the MK1000 on page 2-11.
After completing the mechanical installation of the MK1000, refer to Chapter 3, Setup and
Installation: Communication to establish communication with the host.
