Rear a.v.shield cover/terminal cover – Sanyo CE42LH2WP User Manual
Page 25
5
English
$IWHUFDEOHLQVWDOODWLRQ3/($6(HQVXUHDOOVHDOVDUHFRUUHFWO\ÀWWHGDVVKRZQEHORZSULRUWRUHÀW-
ting the terminal cover and rear A.V.cover. ALL
À[LQJVFUHZVPXVWEHUHSODFHGDQGWLJKWHQHG
REAR A.V.SHIELD COVER/TERMINAL COVER
Check point
1
Check point
2
Check gasket is in place inside the cover.
Gasket is important to seal cable area.
&DEOHVPXVWÀWLQWKHVKDSHRIWKH
recess of the terminal base.
GASKET IN THE TERMINAL
COVER
MAKE SURE CORD FITS IN
THE MOULD SHAPE
GASKET IN THE RECESS
OF THE TERMINAL BASE
