Pc/dvi-d/component signal support timing list – Sanyo CE42LH2WP User Manual
Page 17
17
PC/DVI-D/COMPONENT SIGNAL SUPPORT TIMING LIST
N DVI-D signal support timing
N Component signal support timing
Resolution
+RUL]RQWDO
Frequency
N+]
Vertical
Frequency
+]
Remark
720 x 480
15.735
60i
SDTV 480i
720 x 576
15.625
50i
SDTV 576i
720 x 480
31.25
60p
SDTV 480p
720 x 576
31.25
50p
SDTV 576p
1280 x 720
45.00
60p
HDTV 720p
1280 x 720
37.50
50p
HDTV 720p
1920 x 1080
33.75
60i
HDTV 1080i
1920 x 1080
28.13
50i
HDTV 1080i
Resolution
+RUL]RQWDO
Frequency
N+]
Vertical
Frequency
+]
Remark
640 x 480
31.43
59.88
VGA VESA 60Hz
640 x 480
37.86
72.81
VGA VESA 72Hz
640 x 480
37.5
75
VGA VESA 75Hz
640 x 480
34.97
66.6
MAC LC 13"
640 x 480
35
66.67
MAC_NORMAL 13"
800 x 600
35.16
56.25
SVGA VESA 56Hz
800 x 600
37.88
60.32
SVGA VESA 60Hz
800 x 600
46.875
75
SVGA VESA 75Hz
832 x 624
49.72
74.55
MAC_NORMAL 16"
1024 x 768
48.36
60
XGA VESA 60Hz
1024 x 768
60.23
75.03
XGA VESA 75Hz
1024 x 768
56.47
70.07
XGA VESA 70Hz
1024 x 768
60.24
75.08
MAC_NORMAL 19"
1152 x 870
68.68
75.06
MAC_NORMAL 21"
1280 x 1024
63.98
60.02
SXGA VESA 60Hz
720 x 480
31.7
59.94
480p
720 x 480
15.73
59.94
480i
768 x 575
31.25
50
575p
768 x 575
15.63
50
575i
1280 x 720
37.5
50
720p - 50Hz
1280 x 720
45
60
720p - 60Hz
1366 x 768
48.36
60
WXGA
1360 x 768
47.7
60
WXGA
1920 x 1080
28.125
50
1080i - 50Hz
1920 x 1080
33.75
60
1080i - 60Hz
1920 x 1080
56.25
50
HDTV 1080p - 50Hz
1920 x 1080
67.5
60
HDTV 1080p - 60Hz
1920 x 1080
27.00
24
HDTV 1080p - 24Hz
1920 x 1080
28.13
25
HDTV 1080p - 25Hz
1920 x 1080
33.75
30
HDTV 1080p - 30Hz
N PC signal support timing
Resolution
+RUL]RQWDO
Frequency
N+]
Vertical
Frequency
+]
Remark
720 x 400
31.47
70.09
DOS (VGA)
640 x 480
31.43
59.88
VGA VESA 60Hz
640 x 480
37.50
75.00
VGA VESA 75Hz
640 x 480
37.86
72.81
VGA VESA 72Hz
640 x 480
43.27
85.00
VGA VESA 85Hz
640 x 480
35.00
66.67
Mac. 13
640 x 480
34.97
66.60
Mac LC 13"
800 x 600
35.16
56.25
SVGA VESA 56Hz
800 x 600
37.88
60.32
SVGA VESA 60Hz
800 x 600
46.875
75.00
SVGA VESA 75Hz
800 x 600
34.50
55.38
SVGA
800 x 600
38.00
60.51
SVGA
800 x 600
53.67
85.06
SVGA VESA 85Hz
832 x 624
49.72
74.55
Mac. 16
1024 x 768
48.36
60.00
XGA VESA 60Hz
1024 x 768
56.47
70.07
XGA VESA 70Hz
1024 x 768
60.02
75.03
XGA VESA 75Hz
1024 x 768
48.50
60.02
XGA
1024 x 768
60.31
74.92
XGA
1024 x 768
61.00
75.70
XGA
1024 x 768
68.68
85.00
XGA VESA 85Hz
1024 x 768
60.24
75.08
MAC_Normal 19"
1280 x 720
37.5
50.00
720p - 50Hz
1280 x 960
60.00
60.00
SXGA VESA 60Hz
1280 x 1024
79.976
75.025
SXGA VESA 75Hz
1280 x 1024
63.370
60.01
SXGA
1280 x 1024
63.34
59.98
SXGA
1280 x 1024
63.74
60.01
SXGA
1280 x 1024
63.79
60.18
SXGA
1280 x 1024
63.90
60.00
SXGA
1280 x 1024
81.13
76.107
SXGA
1152 x 900
61.20
65.20
SXGA
1152 x 900
61.85
66.00
SXGA
1152 x 900
71.40
75.60
SXGA
1400 x 1050
65.35
60.12
SXGA +
1400 x 1050
65.12
59.90
SXGA +
1152 x 870
68.68
75.06
MAC_Normal 21"
1280 x 1024
80.00
75.00
Mac II
1600 x 1200
75.00
60.00
UXGA VESA 60Hz
1366 x 768
48.36
60.01
WXGA
1360 x 768
47.73
60.03
WXGA
1920 x 1080
28.125
50.00
1080i - 50Hz
1920 x 1080
33.75
60.00
1080i - 60Hz
The monitor can be automatically adjusted in pc mode when receiving a stan-
dard VESA signal. It will be displayed as XGA when the monitor is receiving a
XGA or WXGA signal.
Depending on the condition of signals and the type and length of cables, these
signals may not be properly viewed.
To save the XGA Mode 1366 x 768 setting switch the monitor off then on using
the standby button.
