10
MENU OPERATION
Language is used to select the preferred language. Use the or
button to select English, French, German, Italian, Spanish or
Dutch.
H-Position changes the OSD position horizontally by using the
or button.
V-Position changes the OSD position vertically by using the or
button.
Duration is used to set the display time of the MENU by using the
or button. (5 ~ 120 seconds)
Transparence is used to adjust transparence of menu display. Use
the
or button to adjust levels.
N PIP/POP Setup
Use the or button to select PIP/POP Setup and press the
or button to enter the sub menu.
PIP/POP Mode: Using the or button select the most suit-
able mode PIP1, PIP2, POP or Off. (Please refer to page 13.)
When Mode is set to Off, Sub Source and PIP Position will not
ZRUN
Main Source is used to select input source (AV1, RGB, AV2, AV3, PC,
'9,RU1HWZRUNIRUPDLQSLFWXUHE\XVLQJWKH or button.
Sub Source is used to select input source (AV1, AV2, AV3, PC or
DVI) for sub picture by using the
or button.
1HWZRUNLQSXWFDQDVVHPEOHZLWKRWKHULQSXWVRXUFH)RUH[DPSOH
if main source is selected as AV1 input, then the sub source must
EH'9,RU1HWZRUNLQSXW
PIP Position: Using the or button it can be selected Top
Left, Top Right, Bottom Right or Bottom Left.
N Initial Settings
This function returns all setting values except for Installation Mode.
N Text Language
Use the or button to select Text Language and press the
or button to select Western, Eastern, Russian, Arabic or
Farsi.
N Tile Mode
This function allows you to split an image to suit your monitor grid
format to create a video wall.
Use the
or button to select Tile Mode and press the or
button to enter the sub menu as follows.
Tile Mode Active can be set On or Off using the
or but-
ton.
H_Sets is used to divide the horizonal picture into more than one
part, but the most is 5 parts (5 monitors).
V_Sets is used to divide the vertical picture into more than one part,
and the most is also 5 parts (5 monitors). Using the
or but-
ton to set.
H Location is used to select one part of the horizonal picture to dis-
play on the current LCD Monitor using the
or button.
V Location is used to select one part of the vertical picture to display
on the current LCD Monitor using the
or button.
%H]HO+$GMXVWPHQW is used to align the image horizontally with
respect to the other monitors in the video wall to accommodate the
bezel width using the
or button. (0 ~ 10)
%H]HO9$GMXVWPHQW is used to align the image vertically with respect
to the other monitors in the video wall to accommodate the bezel
width using the
or button. (0 ~ 10)
N AV2 Setting
Use the or button to select AV2 Setting and press the
or button to select YPbPr or RGBHV.
Connect your PC to either PC-IN or RGBHV on the rear of the set.
Once connected select PC mode or AV2 (RGBHV, see page 6 for AV2
input settings) via the INPUT button on your remote control.
The set will become a monitor for the PC.
N XGA Mode
Use the or button to select XGA Mode and press the or
button to select XGA or WXGA 1366 x 768.
N PC Power Save
The monitor set automatically turns off with no PC input signal and
ZDNHVXSZLWKVLJQDOZKLOH3&3RZHU6DYHLVDFWLYH
Use the
or button to select PC Power Save and press the
or button to select ON or OFF.
PC Adj. menu
Press the MENU button and select PC Adj. using the or
buttons, press the or button to enter. Press the BACK
button to return to the previous menu. Press the MENU button to
exit menu operation.
Auto Adjust is used to automatically detect incoming signal, and
adjust itself to optimize its performance by using the
or
button. If the image is not displayed properly, a manual adjustment is
required (Refer to following adjustments).
H-Position is used to move the horizontal picture position by using
the
or button.
V-Position is used to move the vertical picture position by using the
or button.
Clock LVXVHGWRHOLPLQDWHÀLFNHUIURPWKHLPDJHE\XVLQJWKH or
button.
Phase is used to eliminate disorder from the image by using the
or button.
