Installation
15 38970
Step 5: Position and Level the Washer
Position washer so it has sufficient clearance for
installation and servicing.
Place rubber cups on all four leveling legs.
Place washer in position on a clean, dry, and
reasonably firm floor. Installing the washer on any
type of carpeting is not recommended.
Loosen locknuts and adjust the two front leveling legs.
Once adjusted, tilt the unit forward on front legs and
lower back down into position to set the rear self-
leveling legs.
Washer must not rock. After washer is at desired
height, tighten locknuts securely against bottom of
washer base. If these locknuts are not tight, washer
will not remain stationary during operation.
Improper installation or flexing of weak floor will
cause excessive vibration.
Do not slide washer across floor once the leveling legs
have been extended, as legs and base could become
damaged.
NOTE: For areas with uneven floors, a No. 566P3
Adjustable Rear Leg Extension Kit is available as
optional equipment at extra cost.
Verify that washer does not rock.
Figure 9
Step 6: Connect the Washer to Electrical
Power
Refer to the following section on Electrical
Requirements before connecting the washer to an
electrical power source.
Figure 10
W214I
1 Leveling Leg
2 Washer Base
3 Locknut
4 Rubber Cup
5 15 mm (1/2 inch) Clearance Between
Washers
W214I
2 1
3
5 4
D254I
D254I
