Chapter 5: Advanced Serverboard Setup

5-17

SMB

A System Management Bus header

is located at J22. Connect the ap-

propriate cable here to utilize SMB on

your system.

SMB Power Connector

Connect the SMB power connector

to J24 (located near the ATX power

connector) to utilize SMB.

SMB Header

Pin Defi nitions (J22)

Pin# Defi nition

1

Data

2

Ground

3

Clock

4

No Connection

SMB Power (I

2

C)

Pin Defi nitions (J24)

Pin# Defi nition

1

Clock

2

SMB Data

3

N/A

4

N/A

5

N/A
