AirCard 555 Network Card User Guide
38 2130142
Components of the Watcher
Window
The Watcher window has these components:
• A menu bar on the upper left side of the window
• The Minimize, Toggle Full/Compact, and Close buttons in
the top right corner
• The Data and Voice tabs on the upper right side of the
window
• A section of the window that resembles an LCD screen
(beneath the menu bar) that includes these areas:
· The connection status area at the top
· The call status box in the middle
· The indicator area at the bottom
The Menu Bar
Chapter 7 gives a detailed description of each option in each of
Watcher’s three menus: View, Tools, and Help.
Toggle Full/Compact Button
Button
Manager
Dial-Up
Data/Voice
Control Tabs
Close Button Minimize Button
Menu Bar
Connection Status Area
Call Status Area
Indicator Area
