Port Configuration
3-73
3
Displaying LACP Port Counters
You can display statistics for LACP protocol messages.
Web – Click Port, LACP, Port Counters Information. Select a member port to display
the corresponding information.
Figure 3-44. Displaying LACP Port Counters
CLI – The following example displays LACP counters.
Table 3-6. LACP Statistics
Field Description
LACPDUs Sent Number of valid LACPDUs transmitted from this channel group.
LACPDUs Received Number of valid LACPDUs received on this channel group.
Marker Sent Number of valid Marker PDUs transmitted from this channel group.
Marker Received Number of valid Marker PDUs received by this channel group.
LACPDUs Unknown Pkts Number of frames received that either (1) Carry the Slow Protocols
Ethernet Type value, but contain an unknown PDU, or (2) are addressed
to the Slow Protocols group MAC Address, but do not carry the Slow
Protocols Ethernet Type.
LACPDUs Illegal Pkts Number of frames that carry the Slow Protocols Ethernet Type value, but
contain a badly formed PDU or an illegal value of Protocol Subtype.
Console#show lacp counters 4-125
Port channel : 1
-------------------------------------------------------------------------
Eth 1/ 1
-------------------------------------------------------------------------
LACPDUs Sent : 21
LACPDUs Received : 21
Marker Sent : 0
Marker Received : 0
LACPDUs Unknown Pkts : 0
LACPDUs Illegal Pkts : 0
.
.
.
Console#
