Network setup_ 28
1. Open /opt/Samsung/mfp/share/utils/.
2. Double-click the SetIPApplet.html file.
3. Click to open the TCP/IP configuration window.
4. Enter the machine’s new information into the configuration window.
In a corporate intranet, you may need to have this information
assigned by a network manager before proceeding.
Find the machine’s MAC address from the Network
Configuration Report (see "Printing Network Configuration
report" on page 26) and enter it without the colons. For
example, 00:15:99:29:51:A8 becomes 0015992951A8.
5. The machine will automatically print the Network Configuration
Report.
Network parameter setting
You can also set up the various network settings through the network
administration programs such as SyncThru™ Web Admin Service and
SyncThru™ Web Service.
Restoring factory default settings
You may need to reset the machine to the factory default settings when
machine that you are using is connected to new network environment.
Restoring factory default settings using control panel
1. Press on the control panel.
2. Press up/down arrow to highlight Network and press OK.
3. Press up/down arrow to highlight Clear Settings and press OK.
4. Turn off and restart machine to apply settings.
Restoring factory default settings using SyncThru™
Web Service
1. Start a web browser such as Internet Explorer, Safari or Firefox and
enter your machine’s new IP address in the browser window.
For example,
2. Click Go to access the SyncThru™ Web Service.
3. Click Login on the upper right of the SyncThru™ Web Service
website.
A log-in page appears.
4. Type in the ID and Password then click Login .
If it’s your first time logging into SyncThru™ Web Service, type in the
below default ID and password.
• ID: admin
• Password: sec00000
5. When the SyncThru™ Web Service window opens, click Settings
> Network Settings > Restore Default.
6. Click Clear for network.
7. Turn off and restart machine to apply settings.
Installing wired network connected machine’s driver
You must install the printer driver software for printing. The software
includes drivers, applications, and other user friendly programs.
Make sure that the network setup for your machine is completed. All
applications should be closed on your computer before beginning
installation.
Windows
1. Make sure that the machine is connected to the network and
powered on. Also, your machine’s IP address should have been set.
If the “Found New Hardware Wizard” appears during the
installation procedure, click Cancel to close the window.
2. Insert the supplied software CD into your CD-ROM drive.
The software CD should automatically run and an installation window
will appear.
3. Select Install Now.
When you click the Advanced Installation, you can use the
Custom Installation option. The Custom Installation allows
you to select the machine’s connection and choose individual
components to install. Follow the instructions on the window.
4. Read License Agreement, and select I accept the terms of the
License Agreement. Then, click Next.
The program searches for the machine.
If your machine is not found on the network or locally, an error
message appears.
• Check if you want to install the software without
connection of the printer.
- Check this option to install this program without a
machine connected. In this case, the print a test page
window will be skipped, and completes the installation.
• Search again
When you press this button, the firewall notice window
appears.
- Turn off the firewall and Search again. For Windows
operating system, click Start > Control Panel >
Windows Firewall, and inactivate this option.
- Turn off the firewall from the third party's program
beside the operating system. Refer to the manual
provided by individual programs.
• Direct Input
The Direct Input allows you to search for a specific
machine on the network.
- Search by IP address: Enter the IP address or the host
name. Then click Next.
To verify your machine’s IP address, print a network
configuration report (see "Printing Network
Configuration report" on page 26).
- Search by network path: To find a shared machine
(UNC Path), enter the shared name manually or find a
shared printer by clicking the Browse button. Then click
Next.
• Help
If your machine is not connected to the computer or
network, this help button gives detailed information about
how to connect the machine.
• SNMP Community Name
If your system administrator set the new SNMP
Community Name on the machine, you can find the
machine in the network. Contact your system administrator
for new SNMP Community Name.
5. The searched machines will be shown on the screen. Select the one
you wish to use and click OK.
If the driver searched only one machine, the confirmation
