NIM Primitives 4-10 SIMATIC TIWAY I Series 500 NIM User Manual
Primitive Logical Groups (continued)
The subset of TIWAY I Primitives supported by the Series 500 NIM is given
in Table 4-2. Future additions to this subset will be announced as they are
implemented. Note that each of the following Primitives fits into the general
categories listed in Table 4-1.
Table 4-2 Series 500 NIM Primitive Subset
Primitive Code (HEX)
Non-extended
Address
Extended
Address
Type
00 80 Exception reporting
01 81 Native
02 82 Attached device status
03 83 Attached device type/confirmation
04 84 Primitive format configuration
05 85 Packed native
06 86 Reset secondary device mode
07 87 Segment definition
10 90 Change state
20 A0 Read block (single contiguous block)
21 A1 Read random block
30 B0 Write block (single contiguous block)
31 B1 Write random block
50 D0 Define blocks (up to 32 separate blocks)
51 D1 Gather defined blocks
52 D2 Write and gather defined blocks
55 D5 Define records (up to 32 records)
56 D6 Gather defined records
57 D7 Write and gather defined records
58 D8 Program upload
59 D9 Program download
You can use extended addresses by adding 80hex to the non-extended
address primitive. With extended addresses, the AAAA field is expanded
from sixteen bits to 32 bits (AAAAAAAA). This allows you to access data
element locations beyond the non–extended limit of 65,535. With extended
addresses, you can access up to 4,294,967,296 locations.
Series 500 NIM
Primitive Subset
