Installation 3-7 SIMATIC TIWAY I Series 500 NIM User Manual
Table 3-2 Address Examples
1 25 203
SW8 Open Open Open
SW7 Closed Closed Open
SW6 Closed Closed Closed
SW5 Closed Open Open
SW4 Closed Open Closed
SW3 Closed Closed Closed
SW2 Closed Closed Open
SW1 Closed Closed Open
The upper block of ten dipswitches is used in selecting the parameters that
define the network communication environment. There are two physical
media types over which TIWAY I communication can occur: Siemens Local
Line and RS-232-C. Several dipswitches on the configuration switch block
are ignored when operating on the Local Line media. These switches are
noted in the following descriptions. Selecting Network
Configuration
Parameters
