36
AV28CT1EP / LCT1136-001A-U / English
SPECIFICATIONS SPECIFICATIONS SPECIFICATIONS SPECIFICATIONS
* A basic model number. The actual model number may have characters added (such as “S” denoting silver) indicating the colour
of the TV set.
Design and specifications subject to change without notice.
Pictures displayed on the screen using this TV’s ZOOM functions should not be shown for any commercial or demonstration pur-
pose in public places (cafes, hotels, etc.) without the consent of the owners of copyright of the original picture sources, as this
constitutes an infringement of copyright.
Model
Item
AV28CT1EP*
Broadcasting systems CCIR B/G, I, L
Colour systems PAL, SECAM
• The EXT terminals also support the NTSC 3.58/4.43 MHz system.
Channels and frequencies • E2-E12, E21-E69, S1-S41, X, Y, Z, Z+1, Z+2, A-H, H+1, H+2, F2-F10, F21-F69
• French cable TV channel of broadcast frequencies 116 - 172 MHz and 220 - 469 MHz
Sound-multiplex systems A2 (B/G), NICAM (B/G, I, L) system
Teletext systems FLOF (Fastext), TOP, WST (World Standard System)
Power requirements 220 - 240 V AC, 50 Hz
Power consumption Maximum: 156 W, Average: 122 W, Standby: 0.8 W
Picture tube size Viewable area 66 cm (measured diagonally)
Audio output Rated Power output: 5 W + 5 W
Speakers (10 cm × 3 cm) oval × 2
EXT-1 terminal Euroconnector (21-pin, SCART)
• Video input, Audio L/R inputs and RGB inputs are available.
• TV broadcast outputs (Video and Audio L/R) are available.
EXT-2 terminal Euroconnector (21-pin, SCART)
• Video input, S-VIDEO (Y/C) input and Audio L/R inputs are available.
• Video and Audio L/R outputs are available.
• T-V LINK functions are available.
EXT-3 terminal Euroconnector (21-pin, SCART)
• Video input, S-VIDEO (Y/C) input and Audio L/R inputs are available.
EXT-4 terminal RCA connectors × 3
S-VIDEO connector × 1
• Video input, S-VIDEO (Y/C) input and Audio L/R inputs are available.
Headphone jack Stereo mini-jack (3.5 mm in diameter)
Dimensions (W × H × D) 725 mm × 480 mm × 496 mm
Weight 33.8 kg
Accessories Remote control unit × 1 (RM-C54 (Grey) or RM-C50 (Black) is supplied.)
AAA/R03 dry cell battery × 2
VICTOR COMPANY OF JAPAN, LIMITED
