JVC AV-32R370KE - Manual

© 2003 VICTOR COMPANY OF JAPAN, LIMITED
$95.( /&7$8 (1*/,6+
Colour Television
INSTRUCTIONS
LCT1354-001A-U
0203-MK-CR-JMUK
AV-32R370KE
AV-28R370KE
Specifications
We may change the design and specifications without notice.
Pictures displayed on the screen using this TV’s ZOOM functions should not be shown for any
commercial or demonstration purpose in public places (cafes, hotels, etc.) without the consent of the
owners of copyright of the original picture sources, as this would be an infringement of copyright.
Model
Item
AV-32R370KE AV-28R370KE
Broadcasting systems CCIR I
Colour systems PAL
• The EXT terminals also support the NTSC 3.58/4.43 MHz system.
Channels and frequencies E21-E69
Sound-multiplex systems NICAM (I) system
Teletext systems
FLOF (Fastext), WST (World Standard Text)
Power requirements 220 - 240 V AC, 50 Hz
Power consumption Maximum: 200 W, Average: 127 W,
Standby: 3 W
Maximum: 200 W, Average: 125 W,
Standby: 3 W
Picture tube size Viewable area 76 cm (measured
diagonally)
Viewable area 66 cm (measured
diagonally)
Audio output Rated Power output: 10 W + 10 W + 10 W, 18 W (woofer)
Speakers (13 cm × 6.5 cm) oval × 2, (16 cm × 4 cm) oval × 1, 13 cm round woofer ×1
EXT-1 terminal Euroconnector (21-pin, SCART)
• Video input, Audio L/R inputs and RGB inputs are available.
• TV broadcast outputs (Video and Audio L/R) are available.
EXT-2 terminal Euroconnector (21-pin, SCART)
• Video input, S-VIDEO (Y/C) input and Audio L/R inputs are available.
• Video and Audio L/R outputs are available.
• T-V LINK functions are available.
EXT-3 terminal Euroconnector (21-pin, SCART)
• Video input, S-VIDEO (Y/C) input and Audio L/R inputs are available.
EXT-4 terminal RCA connectors × 3
S-VIDEO connector × 1
• Video input, S-VIDEO (Y/C) input and Audio L/R inputs are available.
AUDIO OUT terminal RCA connectors × 2
• Variable audio L/R outputs are available.
• Variable out 0-1 Vrms, low impedance.
SURROUND REAR
terminal
SPEAKER terminals for external surround speakers.
• Surround rear sounds are output to the speakers.
• For impedance 8-ohm speakers only.
• Rated power output: 7.5 W + 7.5 W
Headphone jack Stereo mini-jack (3.5 mm in diameter)
Dimensions (W × H × D) 946 mm × 562 mm × 551 mm 854 mm × 507 mm × 494 mm
Weight 57.5 kg 43.0 kg
Accessories Remote control unit × 1 (RM-C1504)
AA/R6 dry cell battery × 2
Contents
Setting up your TV. . . . . . . . . . . . . . . . . 5
TV buttons and functions. . . . . . . . . . . 10
Remote control buttons and functions . . .11
Teletext function . . . . . . . . . . . . . . . . . 16
Using the TV’s menu . . . . . . . . . . . . . . 18
Additional menu operations . . . . . . . . . 35
Additional preparation . . . . . . . . . . . . . 39
Troubleshooting. . . . . . . . . . . . . . . . . . 42
Specifications . . . . . . . . . . . . Back cover
AV
-32R3
70KE
/AV
-28R3
70KE
