JVC T-V Link AV28CT1EP - Manual (Page 34)

33
ENG
L
ISH
AV28CT1EP / LCT1136-001A-U / English
TV BUTTONS AND PARTS TV BUTTONS AND PARTS TV BUTTONS AND PARTS TV BUTTONS AND PARTS
■ ■ ■ ■ Front Panel Front Panel Front Panel Front Panel
Caution:
• Do not grasp the TV by the front panel cover when moving the TV set. If you do, you may break the cover.
■ ■ ■ ■ Rear Panel Rear Panel Rear Panel Rear Panel
1 Remote control sensor 5 P
∨∨∨∨
/
∧ ∧ ∧ ∧
buttons / q q q q buttons page 8
2 Headphone jack (mini jack) page 30 6 Power lamp pages 3 and 6
3 EXT-4 terminal pages 19 and 30 7 Main power button pages 3 and 6
4 r r r r
(Volume) button page 8
Push to open
(Behind the cover)
8 Aerial socket page 2 0 EXT-2 terminal pages 2, 5, 19 and 30
9 EXT-1 terminal pages 2, 19 and 30 - EXT-3 terminal pages 19 and 30
EXT- 2
EXT- 1
EXT- 3
S S
EXT- 1
