21
4.
Turn the camera
Make sure that the camera is horizontal,
followed by fitting the camera to the ceiling
mount and turning it in the clockwise direction
until it stops. Upon doing so, check that the
the camera clamping bracket is aligned with
the position of the locking screw of the ceiling
mount.
5.
Fasten the locking screw
Fasten the locking screw using a flathead
screwdriver.
* To dismantle the camera, perform procedure
from steps 1 to 5 in the reverse order.
If the locking screw is not securely fastened,
the camera may vibrate or fall down.
Be sure to fasten the locking screw firmly.
Camera clamping bracket
Rotate the
camera
clockwise.
Locking Screw
Tighten the locking screw.
Cautions
