JVC VIDEO PLUS HR-S6965EK - Manual (Page 7)

equipment key 7
Diagram Key
* DECODER function is not available in the
UK.
FRONT PANEL
1 STANDBY/ON o Button
turns VCR on/off (loading a
cassette also turns power on).
2
Cassette Loading Slot is
where cassette is inserted;
door closes.
3
24H EXPRESS c Button
enables 24H Express Timer
Programming.
4
Advanced JOG Dial enables
picture search, preset position
selection or 24H Express
Timer Programming.
5 c
Button engages timer—
standby mode.
6 b
(Display) Button
switches display between
clock time and Preset
Position *(or Mode).
* Preset Position (or Mode) is
not displayed during playback.
7 Display Panel provides
clear view of various displays
and indicators.
8
Infrared Beam Receiving
Window is where Remote
Control should be aimed when
in use.
9
0000 Button resets
countenance the on-screen
display to ‘0:00:00’.
10
SP/LP Button select tape
speed.
11 T
Button starts regular
recording (press once), Instant
Timer Recording (press twice);
sets duration of ITR.
12 |
Button stops tape
temporarily during recording;
stops tape temporarily during
playback; plays back frame by
frame with each additional
press.
SATc Button enables/
disables the Auto Satellite
Programme Recording mode.
13
§
Button stops tape;
ejects tape during Stop mode.
14 .
Button plays back tape;
cancels Pause, Still, Slow,
Search modes.
REAR PANEL
1 Mains Power Cord
supplies power to VCR.
2 ANT. IN Connector
enables connection of aerial.
3
L-2 IN/DECODER
Connector enables connection
of satellite receiver or second
recorder.
4 L-1 IN/OUT Connector
enables AV connection to TV
or second VCR.
5 AUDIO OUT (L/R)
Connectors enable connection
of audio cassette recorder, TV
or second VCR for dubbing.
6
RF. OUT Connector enables
connection to aerial terminal
of TV receiver.
VCR DISPLAY PANEL
1 Indicator blinks after
timer-recording and shows
how many programmes have
been timer-recorded.
2
Play Indicator lights up
during playback; blinks during
Repeat Playback or when
using Next Function Memory
for playback.
3
Record Indicator lights up
during recording; blinks
during Instant Timer
Recording.
4
Channel Display shows
preset position where the
station currently being
received is stored.
Mode shows external input
mode selected (L-1 or L-2)
Clock Display shows
current time.
Preset Position* (or Mode)
and Clock Display appear
alternately when b is
pressed.
* Preset Position (or Mode) is
not displayed during playback.
5 Indicator lights up
during Auto Satelite
Programme Recording
standby model; blinks when
Auto Satelite Programme
Recording in progress.
6 c
Indicator lights when
the c button has been
pressed to engage Timer
mode.
7
VCR Indicator lights when
the VCR is in the video mode.
At this point, the TV
automatically enters AV
mode.
8
Programme Stop Time
Indicator shows the
programme stop time for
24H Express Timer
Programming.
9 S-VHS Indicator lights
when a cassette marked
S-VHS is inserted with S-VHS
mode set to ‘ON’, when an
S-VHS-recorded tape or
S-VHS ET-recorded tape is
played back, or when S-VHS
ET mode is engaged.
10
Programme Start Time
Indicator shows the
programme start time for
24H Express Timer
Programming.
REMOTE CONTROL
1 TV STANDBY/ON o
Button turns TV on/off.
2
TV/VCR Button switches
connected TV’s mode between
TV and AV.
3
TV Button switches TV
input terminal.
4
START + / – Buttons
inputs programme Start Time.
5
STOP + / – Buttons inputs
programme Stop Time.
6
PDC Button enables/
disables PDC recording.
* VPS (Video Programme
System) recording is not currently
available in the U.K. and not
possible with this VCR.
7 x Button cancels timer-
programme.
0000 Button resets
counter on the on-screen
display to ‘0:00:00’.
8
PROG Button accesses
Timer Programming Set
screen.
9 C
Button accesses
Program screens/displays to
check the programme that you
have programmed (next
programme’s information
screen appears each time
button is pressed).
10 <
Button rewinds
the tape; inltiates reverse
picture search.
11 T
Button — same as
button on VCR.
12 S
Button stops tape.
13 TV PR +/– Buttons select
the connected JVC TV's
channel.
14 r
Button
‘reviews’ timer-recorded
programme.
15
Button accesses
Menu screen.
16 STANDBY/ON o Button
— same as button on VCR.
17
AUDIO Button changes
output sound mode.
18 b
(Display) Button
switches display between
clock time and Preset
Position* (or Mode).
Preset Position (or Mode) is not
displayed during playback.
19 Number Keys are used in
preset position selection and
the VIDEO Plus+ Timer
Programming.
20
DATE + / – Buttons inputs
date of programme for timer
recording
21
DAILY Button enables
timer recording of daily
serials.
22
WEEKLY Button enables
timer recording of weekly
serials.
23
AUX Button selects VCR’s
auxiliary input mode.
24 c
Button engages timer-
standby mode.
25
Auto Tracking Button
enables/disables auto
tracking mode during
playback.
/ Button selects tape
speed.
26 3
Button
initiates a 30-second period of
fast-motion playback.
27 .
Button — same as
button on VCR.
28 >
Button fast-
forwards tape; inltiates
forward picture search.
29 |
Button — same as
button on VCR.
30
PR PR
Buttons are used
for selection in on-screen
menus.
PR + / – Buttons select a
preset position.
31
TV +/– Buttons control
volume of connected JVC TV.
32 D E
Buttons initiate
functions such as Index
Search, variable-speed search,
frame by frame playback.
33
Button enters
selections made in on-screen
menus.
Button — Shows
current VCR status on the TV
screen if O.S.D is set to ON.
