10
EN
AP-V20U
BN-VF815U
AC Adapter Battery Pack
Component Cable AV Cable
LY37115-001B
USB Cable Shoe Adapter
RM-V760U CR2025
Remote Control Lithium Battery
Pre-installed in the
remote control.
CD-ROM
NOTE
Make sure to use the provided cables for
connections. Do not use any other cables.
Accessories
GETTING STARTED
Shoe Adapter
An optional microphone or light can be
attached to the shoe adapter.
Slide the shoe cover
in the direction of the
arrow to reveal the shoe
adapter mounting socket.
Mount the accessory
shoe adapter.
Fasten the shoe adapter
to the shoe adapter
mounting socket by
turning the screw in the
direction of the arrow.
Insert a microphone, etc.
from behind the shoe
adapter.
NOTE
Do not try to attach a microphone, etc. to the
shoe adapter forcibly.
GETTING ST
AR
TED
