18
1 Load the tape.
The power is turned on. Playback automatically
starts with the tape protected (without safety tab).
2 Press the PLAY button.
Playback starts.
Press the PAUSE/STILL button to obtain a still
picture. Playback resumes by pressing the PLAY
button.
To monitor the HD-recorded tape, set the input
select switch on the high vision TV to HD input.
3 Press the STOP button to bring the playback to
an end.
Notes:
● With the still picture or slow play remaining for
longer than five minutes, the STOP mode is
automatically entered to protect the tape from
damage.
● In HD mode, the still picture may fail to come up
when quickly switching from PLAY to STILL.
Basic Procedure
Audio Select
4 How to select HiFi audio channel?
a. Select with the HI-FI AUDIO SELECT button.
Every pressing the button changes HiFiL,R [
HiFiL [ HiFiR.
b. Check the audio output display on the front
panel display window.
L R : left and right audio
L : left audio
R : right audio
When selecting a reproduced audio (HiFi audio/
normal audio)
a. Select with the AUDIO OUT SELECT button.
Every pressing the button changes HiFi audio
[ normal audio. The tape for which HiFi audio
has not been recorded reproduces normal
audio.
b. Check the audio output display on the front
panel display window.
L R : HiFi audio
No display : normal audio
Note:
Since normal audio is not recorded on a W-VHS
tape, selection between normal and mix audio is
not possible on a tape like that.
6 PLAYBACK
4
OPERATE HI-FI AUDIO
SELECT
EJECT
BALANCE REC LEVEL
L R 0 10
AUDIO OUT
SELECT
629
TBC
COUNTER
/REMAIN
COUNTER
RESET
ZERO
SEARCH
MARK ERASE
OPERATE HD SD S-VHS IN — R.A.E. — OUT
REW FF
INDEX SEARCH
INSERT A.DUB
REC SP/EP
HD INPUT R.A.EDIT
IN/OUT
REV
FWD
START
PREROLL EDIT
START
JOG
SHUTTLE
PAUSE
STOP PLAY PAUSE/STIL
INPUT
SELECT
INDEX
1
3 2
