ENGLISH Grip Strap ( ੬ p. 18)
USB (Universal Serial Bus) Connector [ ]
( ੬ p. 46, 55, 62)
HDMI Connector [HDMI] ( ੬ p. 35)
Component Connector [COMPONENT]
( ੬ p. 35)
Audio/Video Connector [AV] ( ੬ p. 36, 50)
i.LINK Connector [ i ] ( ੬ p. 49)
Remote Sensor ( ੬ p. 11)
Lens Cover/Lens
GZ-HD6 Lens Hood ( ੬ p. 10)
Shoe
microSD Card Slot (
੬ p. 19)
Stud Hole ( ੬ p. 18)
Tripod Mounting Socket ( ੬ p. 18)
Fan inlet
Battery Release Button [BATT.] (
੬ p. 16)
Battery Pack Mount ( ੬ p. 16)
Remote Control
Infrared Beam Transmitting Window
ZOOM (T/W) Buttons
(Zoom in/out during playback.)
Up Button
Rotate Button (counterclockwise) ( ੬ p. 30)
Skip Backward Button
Left Button
Back Button
PLAYLIST Button (
੬ p. 43)
START/STOP Button
SNAPSHOT Button (
੬ p. 21)
INFO Button ( ੬ p. 39)
Skip Forward Button
PLAY/PAUSE Button
Right Button
Next Button
Down Button
Rotate Button (clockwise) ( ੬ p. 30)
INDEX Button
DATE Button
NOTE
You can move the zooming area with the up/
down/left/right button during zoom in playback
mode.
Camera
Index Button [INDEX] ( ੬ p. 31)/
Remaining Space Button/
Data Battery Button [ /
] ( ੬ p. 23)
Set Lever
Move to :
Reverse Skip ( ੬ p. 29)/Up/ Backlight
Compensation Button [BACK LIGHT]
(
੬ p. 25)
Move to :
Forward Skip ( ੬ p. 29)/Down/ Manual
Focus Button [FOCUS] ( ੬ p. 25)
Move to :
Reverse Search ( ੬ p. 29)/Left/Nightalive
[NIGHT] ( ੬ p. 25)
Move to :
Forward Search ( ੬ p. 29)/Right/Program
AE [PROGRAM AE] ( ੬ p. 24)
Press down:
Play/Pause ( ੬ p. 29)
Function Button [FUNCTION] ( ੬ p. 26)
Auto/Manual Mode Button [AUTO]
( ੬ p. 24)/Information Button [INFO]
( ੬ p. 39)
Fan outlet
Playback/Recording Mode Switching
Button [PLAY/REC] ( ੬ p. 20)
Zoom Lever [W , T ] ( ੬ p. 22)
Speaker Volume Control [–VOL+] ( ੬ p. 29)
Still Image Shooting Button [SNAPSHOT]
( ੬ p. 21)
Access/Charge Lamp [ACCESS/CHARGE]
( ੬ p. 16) (Blinks when you access fi les
or charge the battery. Do not turn off the
power or remove the battery pack/AC
adapter while accessing fi les.)
Video/Still Image Mode Lamp [ , ]
( ੬ p. 20, 21)
LCD Monitor
Direct Backup Button [DIRECT BACK UP]
( ੬ p. 56)/Event Button [EVENT] (੬ p. 22)
Focus Assist Button [FOCUS ASSIST]
( ੬ p. 25)
Menu Button [MENU] ( ੬ p. 17, 66)
Video Recording Start/Stop Button [REC]
( ੬ p. 20)
DC Input Connector [DC] ( ੬ p. 16)
Microphone Input Connector [MIC]
GZ-HD6 Headphone Connector
Power/Mode Switch [OFF (CHARGE), ON,
MODE] ( ੬ p. 16)
Stereo Microphone
