65
English
This remote control supplied with the receiver can transmit control signals for other
manufacturers’ VCRs, TVs, CATV converters and DBS tuners. By changing the
transmittable signals from preset ones to the other manufacturers’, you can operate the
other manufacturer’s components using this remote control.
When operating the other manufacturers’ components, refer also to the manuals
supplied with them.
To operate these components with the remote control, first you need to set the
manufacturer’s code each for the VCR, TV, CATV converter, and DBS tuner.
IMPORTANT:
When using the Remote Control, check to see if its remote control
mode selector is set to the correct position:
To operate an audio system, TV, and VCR, set it to “AUDIO/TV/
VCR.”
To operate a CATV converter and DBS tuner, set it to “CATV/
DBS.”
To change the transmittable signals for operating another
manufacturer’s TV
1. Set the remote control mode selector to “AUDIO/TV/
VCR.”
2. Press and hold TV/CATV/DBS .
3. Press TV/DBS.
4. Enter the manufacturer’s code (three digits) using
buttons 1 – 9, and 0.
See the lists on page 68 to find the code.
5. Release TV/CATV/DBS .
The following buttons can be used for operating the TV
(with the remote control mode selector set to “AUDIO/TV/
VCR”):
TV/CATV/DBS
: Turns on and off TV.
TV VOLUME +/–: Adjusts the volume.
TV/VIDEO: Sets the input mode (either TV
or VIDEO).
After pressing TV/DBS (with the remote control mode
selector set to “AUDIO/TV/VCR”), you can perform the
following operations on the TV:
CHANNEL +/–:
Changes the channels.
1 – 10, 0, 100+(+10): Selects the TV channels.
100+(+10) button will function as the
ENTER button if your TV requires
pressing ENTER after selecting a
channel number.
6. Try to operate your TV by pressing TV/CATV/DBS .
When your TV turns on or off, you have entered the correct code.
7. If there are more than one code listed for your brand of TV, try each one until
the correct one is entered.
Operating Other Manufactures’ Components
AUDIO/TV
/VCR
CATV
/DBS
Note:
Refer also to the manual
supplied with your TV.
O N
SC REEN CON TR
O L
RM-SR774XU REMOTE CONTROL
/DBS
SURROUND
MODE
SOUND
CONTROL
CD
DISC
VCR SLEEP AUDIO
DVD MULTI DVD TV/DBS VCR
CD
SEA
MODE
TEST
(REAR R)
REAR (L)
DELAY
TAPE/MD FM/AM PHONO
5 4 6
2 1 3
8 7 /P 9
0 +10 10
AUDIO/TV
/VCR
SET EXIT
VCR TAPE CONTROL
VOLUME
CHANNEL
MUTE
FF / ¢
PLAY
STOP
REC
TV/VIDEO
TV VOLUME
PAUSE
4 / REW
TV/CATV
CNTR CNTR TONE
ENTER
MENU
EFFECT
CATV
/DBS
FM MODE/MUTE 100+ RETURN
TUNING UP
MENU
TUN ING DOW N
