CHAPTER 4
Site Preparation
• Site Preparation Checklist for EX2200 Switches on page 33
• General Site Guidelines for EX Series Switches on page 35
• Site Electrical Wiring Guidelines for EX Series Switches on page 35
• Environmental Requirements and Specifications for EX Series Switches on page 36
Site Preparation Checklist for EX2200 Switches
The checklist in Table 15 on page 33 summarizes the tasks you need to perform when
preparing a site for EX2200 switch installation.
Table 15: Site Preparation Checklist
Date Performed By For More Information Item or Task
Environment
“Environmental Requirements and
Specifications for EX Series Switches”
on page 36 Verify that environmental factors such as
temperature and humidity do not exceed switch
tolerances.
Power
Measure distance between external power
sources and switch installation site.
Locate sites for connection of system
grounding.
“Power Specifications for EX2200
Switches” on page 47 Calculate the power consumption and
requirements.
Hardware Configuration
“EX2200 Switches Hardware
Overview” on page 3 Choose the number and types of switches you
want to install.
Rack or Cabinet
