Chassis Physical Specifications for EX2200 Switches
The EX2200 switch chassis is a rigid sheet-metal structure that houses the hardware
components. Table 2 on page 5 summarizes the physical specifications of the EX2200
switch chassis.
Table 2: Physical Specifications of the EX2200 Switch Chassis
Value Description
1.75 in. (4.45 cm) Chassis height
• 17.5 in. (44.5 cm)
• 19 in. (48.2 cm) with mounting brackets attached
Chassis width
10.5 in. (26.7 cm) Chassis depth
• EX2200-24T: 6 lb (2.7 kg)
• EX2200-24P: 8 lb (3.6 kg)
• EX2200-48T: 8 lb (3.6 kg)
• EX2200-48P: 10 lb (4.5 kg)
Weight
Related
Documentation
Rack Requirements for EX2200 Switches on page 39 •
• Cabinet Requirements for EX2200 Switches on page 40
• Mounting an EX2200 Switch on page 53
• Installing and Connecting an EX2200 Switch on page 51
Front Panel of an EX2200 Switch
The front panel of an EX2200 switch consists of the following components:
• Network ports—depending on the switch model, either of:
• 24 or 48 10/100/1000Base-T Gigabit Ethernet ports, with Power over Ethernet (PoE)
not available in EX2200-24T and EX2200-48T
• 24 or 48 10/100/1000Base-T Gigabit Ethernet ports, with Power over Ethernet (PoE)
available in EX2200-24P and EX2200-48P
• 4 built-in SFP uplink ports
• 2 chassis status LEDs
• 4 port status mode LEDs
• Mode button
Figure 1 on page 6 shows the front panel of an EX2200 switch with 48 Gigabit Ethernet
ports. Figure 2 on page 6 shows the front panel of an EX2200 switch with 24 Gigabit
Ethernet ports.
