JVC SR-VS20U - Manual (Page 76)

GENERAL
Power requirement
: AC 120 V`, 60 Hz
Power consumption
Power on : 35 W
Power off : 5.5 W
Temperature
Operating
: 5°C to 40°C (41°F to 104°F)
Storage : –20°C to 60°C (–4°F to 140°F)
Operating position : Horizontal only
Dimensions (WxHxD) : 435 mm x 127 mm x 390 mm
Weight
: 6.9 kg
Input/Output : RCA connectors:
(IN x 2, OUT x 2)
S-Video connectors:
(IN x 2, OUT x 2)
DV connectors: (IN/OUT x 1)
(4-pin, IEEE1394 conformity,
digital input/output)
VHS DECK VIDEO/AUDIO
Signal system
: NTSC-type colour signal and EIA
monochrome signal, 525 lines/
60 fields
Recording system : DA4 (Double Azimuth) head
helical scan system
Format : S-VHS/VHS NTSC standard
Signal-to-noise ratio : 45 dB
Horizontal resolution : 240 lines (VHS)
400 lines (S-VHS)
Frequency range : 70 Hz to 10,000 Hz
(Normal audio)
20 Hz to 20,000 Hz
(Hi-Fi audio)
Maximum recording time
(SP) : 210 min. with ST-210 video
cassette
(EP) : 630 min. with ST-210 video
cassette
DV DECK VIDEO/AUDIO
Signal system
: NTSC-type colour signal,
525 lines/60 fields
Recording system : Digital Component Recording
Format : DV format (SD mode)
Cassette : Mini DV Cassette
Maximum recording time
(SP) : 60 min. with M-DV60ME
cassette
(LP) : 90 min. with M-DV60ME
cassette
Audio recording system
: PCM 48 kHz, 16 bit (2 ch)/
32 kHz, 12 bit (4 ch)
SPECIFICATIONS
TUNER
Tuning system
: Frequency-synthesized tuner
Channel coverage
VHF : Channels 2–13
UHF : Channels 14–69
CATV : 113 Channels
TIMER
Clock reference
: Quartz
Program capacity : 1-year programmable timer/
6 programs each on the VHS
and DV deck
Memory backup time : Approx. 60 min.
ACCESSORIES
Provided accessories
: RF cable (F-type),
BNC/RCA adapter x 2,
Infrared remote control unit,
“AA” battery x 2,
Audio/Video Cable,
S-Video cable (4-pin),
Controller
Specifications shown are for SP mode unless otherwise specified.
E. & O.E. Design and specifications subject to change without
notice.
This equipment has been tested and found to comply with
the limits for a Class A digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when
the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accor-
dance with the instruction manual, may cause harmful
interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful
interference in which case the user will be required to
correct the interference at his own expense.
SR-VS20U
COPYRIGHT 2001 VICTOR COMPANY OF JAPAN, LTD.
U/U(C)
Printed in Japan
0301 IYV
* ID * VP
VICTOR COMPANY OF JAPAN, LIMITED
