JVC GD-V4211PCE - Manual (Page 40)

40
Specifications
(Continued)
Pin assignment (Specifications for terminals)
• Y/C terminal • RS-232C terminal
This is a female type connector.
1 2
3 4
Pin number Signal name
1 GND (Y)
2 GND (C)
3 Y
4 C
Pin number Signal name
1 DCD
2 RD
3 TD
4 DTR
5 GND
Pin number Signal name
6 DSR
7 RTS
8 CTS
9 RI
4 3 2 1
9 8
5
7 6
• RGB Input Terminal
Pin number Signal name
1 Red
2 Green
3 Blue
4 N/C
5 GND
6 GND
7 GND
8 GND
Pin number Signal name
9 N/C
10 GND
11 GND
12 N/C
13 HD/Cs
14 VD
15 N/C
External GND
1
2
8
4
5
6
7
3
9
10
11
12
13
14
15
Unit: mm (inch)
Side view
Top view
Front view
Dimensions
MENU INPUT POWER
1035 (40 ) / 4 3 89 (3 )
11 ( ) / 2 1
57.5 (2 ) / 8 3
570 (22 )
/ 2
1
17
( )
/ 16
11
997 (39 ) / 8 3
940 (37 ) / 8 1
921 (36 ) / 8 3
640 (25 )
/ 4
1
577 (22 )
/ 4
3
518.4 (20 )
/ 2
1
/ 8 5
