38
Specifications
General
* 1
* 1
* 1
* 1
* 1
* 1
* 1
* 1
* 1
* 1
Model name GD-V4210PZW / GD-V4210PZW-G GD-V4210PCE / GD-V4210PCE-G /
GD-V4211PCE
Frame color GD-V4210PZW: Silver GD-V4210PCE / GD-V4211PCE: Silver
GD-V4210PZW-G: Gray GD-V4210PCE-G: Gray
Screen size Type 42 wide format
Aspect ratio 16:9 (Wide format)
Number of pixels displayed 853 (H) x 480 (V)
Number of colors displayed 16.77 million (256 colors for each of RGB)
Effective screen size 92.1 cm x 51.8 cm (36-3/8” x 20-1/2”), 105.7 cm (41-5/8”)
(W x H, Diagonally)
Weight 35.8 k g (78.8 lbs.)
External dimensions 103.5 cm x 64.0 cm x 8.9 cm (40-3/4” x 25-1/4” x 3-5/8”)
(W x H x D) * Excluding protruding parts
Power requirements AC 120 V / AC 230 V, 50 Hz/60 Hz
Rated input current 3.5 A (AC 120 V) / 1.9 A (AC 230 V)
Compatible systems
VIDEO A, B input NTSC, NTSC 4.43, PAL, SECAM
COMPONENT input 480i, 576i, 480p, 720p, 1080i (1035i)
Audio power output INTERNAL: 2 W + 2 W (TYP at impedance 8 Ω )
EXTERNAL: 3 W + 3 W (TYP at impedance 6 Ω )
Built-in speakers 2 pcs., 4 cm x 7 cm oval-shaped, impedance 6
Ω
Operating conditions Temperature: 0 °C to 40 °C
Relative humidity: 20 % to 80 % (non-condensation)
VIDEO A
Video input BNC terminal x 1, 1 V(p-p), 75
Ω
Video output BNC terminal x 1, 1 V(p-p), 75 Ω
Audio input Pin jack terminal x 2 (L/R)
500 mV(rms), high impedance
VIDEO B
Y/C input Y/C terminal x 1
Y: 1 V(p-p), 75 Ω
C: 0.286 V(p-p), 75 Ω (for NTSC)
C: 0.3 V(p-p), 75 Ω (for PAL/SECAM)
Video input Pin jack terminal x 1, 1 V(p-p), 75
Ω
Audio input Pin jack terminal x 2 (L/R)
500 mV(rms), high impedance
COMPONENT
COMPONENT input BNC terminal x 3
Y: 1 V(p-p), 75
Ω
P B /B-Y: 0.7 V(p-p), 75
Ω
P R /R-Y: 0.7 V(p-p), 75
Ω
Audio input Pin jack terminal x 2 (L/R)
500 mV(rms), high impedance
Input/output terminals*
1
A
V
ter
minals*
1
