14
Basic Operations
Daily Operations
1
Turn on the main power.
Set MAIN POWER on the back of the Monitor to ON.
The POWER lamp on the upper left of the front panel
glows orange.
2
Turn on the power.
Press POWER on the remote control to turn the power on.
The POWER lamp changes to glow green.
• You can also use the POWER on the front panel (lower
right) to turn on the Monitor.
3
Select an input.
Select the desired input by pressing VIDEO A, VIDEO B,
COMPO. or RGB.
• You can also select the input by pressing INPUT on the
Monitor. Each time you press the button, the input
mode changes in sequence.
• Only for GD-V4210PCE, GD-V4210PCE-G, and
GD-V4211PCE: You can only select RGB.*
Note:
• This Monitor has two RGB input terminals — RGB A and
RGB B.
When you select the RGB input, the one set on the menu
(RGB INPUT: see page 23) is selected as the input source.
If you want to select the other RGB input than the current
one, change the RGB INPUT setting on the menu.
4
Adjust the volume.
Notes:
• While no menu is displayed, you can adjust the volume by
pressing 2 / 3 on the Monitor.
• When the INTERNAL/EXTERNAL selecting switch on the
back of the Monitor is set to EXTERNAL, no sounds come
out of the built-in speakers.
When you want to hear audio sound from the built-in
speakers, set the INTERNAL/EXTERNAL selecting switch
to INTERNAL.
To turn off the volume immediately
Press MUTING.
“MUTING ON” is displayed, and the sound goes out.
Pressing the button again resumes the previous volume level.
To make the screen indication appear
Press DISPLAY .
The types of input and signal are indicated on the screen for
about 3 seconds.
You can also make the screen indication appear using menus
(page 24).
Rear View
4
3
2
MUTING
DISPLAY
DISPLAY ASPECT POWER
RGB COMPO. VIDEO B
VOLUME
MULTIPLE
MODE ID SET
MONITOR ADJUSTMENT
VIDEO A
MUTING
MENU/EXIT
RM-C575 REMOTE CONTROL UNIT
ID
, ,, ,,
I
1
VIDEO A VIDEO B
RGB A or RGB B COMPO.
V I D E O A
N T S C
Input selected
Input video signal
Ex. When selecting “VIDEO A” input
: 2 5 V O L U M E
+ –
* Only for GD-V4210PCE, GD-V4210PCE-G, and GD-V4211PCE: You need to install the video interface kit (IF-C421P1W), which
is separately purchased, to reproduce input images for VIDEO A, VIDEO B, and COMPONENT.
