29
PICTURE FORMAT SETTING
Set-up
Capture Mode
Image Format
Device Change
Initialize
ID Change
Counter Reset
SELECTING A PICTURE FORMAT
Under "Image Format", you can specify the full image format and the capture mode.
3 Select capture mode.
•There are two different settings avail-
able: "Frame Picture" and "Field
Picture". Refer to "Capture Mode"
below for details.
4 Click "OK".
•This completes picture format setting.
•This setting takes effect the next time
you use the capture function.
1 At the menu bar,
click "Set-up" —
"
Image Format ".
•The "Image
Format" window
appears.
2 Select format.
•There are two different settings avail-
able: "JPEG (
9
. jpg)" and "Bitmap (
9
.
bmp)". Refer to "Picture Data Format"
below for details.
TRANSFER DATA
The full image can be captured and transferred in two different formats.
Picture Data Format
● JPEG ( 9
. jpg)
• This is the default setting. If you do not set Picture Format, image data is captured in this
format.
• JPEG (Joint Photographic Expert Group) is a leading standard defining the compression and
decompression of still color pictures.
• The size of transferred image is smaller because the images are compressed. This results in a
shorter transfer time.
● Bitmap ( 9
. bmp)
• Transfer time is longer when you use this format because there is no data compression. The
benefit is that picture quality is maintained with no deterioration.
• Bitmap is a data format representing characters and graphics with combinations of pixels.
Full image resolution is 640 x 480 pixels with 16.77 million colors (24-bit color).
Index image resolution is 80 x 60 pixels with 16.77 million colors (24-bit color).
Capture Mode
● Frame Picture
• This is the default setting. If you do not set Picture Format, images are captured in this
mode.
• Since a frame consists of two overlapping 1/60 sec. images (one 1/30 sec. image forms a
field), it is unstable when capturing fast-moving motion pictures.
● Field Picture
• While a field contains only half the data of a frame — meaning that vertical resolution is
half that of a frame — images captured from a fast-moving motion picture are more stable
than when captured with "Frame Picture".
