24
VIDEO CAPTURE
CAPTURING VIDEO IMAGES
There are three capture modes available: Step by Step, Program and Interval. The latter two
modes are available only when connected to a JLIP compatible video source unit. Step by Step
Capture mode must be used to capture images from a video source unit with no JLIP connector.
Image data flow
Video source
unit
Video signal
GV-DS1
(Image stored in video memory)
PC
(images are stored on a hard disk or the like)
Index image
(with a resolution of
80 x 60 pixels)
Full image
(with a resolution of 640 x 480
pixels)
2 types of full size images
• Bitmap format Approx. 900 kB
• JPEG format Approx. 50 kB
When storing images on a 2HD disk,
• One image saved in the bitmap data format can be stored on one disk.
• About 28 images saved in the JPEG format can be stored on one disk.
This is the case when using floppy disks formatted for 1.44 MB.
NOTE:
•The index image is displayed in the
image display box.
•Each time the image display box is
double-clicked, the full image (640 x
480 pixels) is displayed only after vieo
data transfer is finished.
