AS/400 Prompt

AS/400

Parameter

RIPSS Configuration

Display

RIPSS Prompt

Exchange identifier EXCHID

SDLC Server Data

Block number (hex) and XID (hex)

For SDLC connections, the values specified for the
RIPSS configuration must match the value
specified in the EXCHID parameter of the
CRTCTLRTL command. The EXCHID parameter
must be specified as:

xxxyyyyy, where xxx

matches the RIPSS Block number and

yyyyy

matches the RIPSS XID.

For switched connections, the block number must
be 005.

Local location
address

LOCADR

SNA Server Data,
Session Data

LOC Address (Dec)

The values specified for the RIPSS configuration
must match the values specified on the LOCADR
parameter of the CRTDEVRTL command.

Note that the RIPSS LOC Address is a decimal
value; the AS/400 value is a 2-digit hexadecimal
number.

NRZI data
encoding

NRZI

SDLC Server Data

Data coding/decoding

For SDLC connections, the values specified for the
AS/400 CRTLINSDLC command and the RIPSS
configuration must match:
v If the RIPSS response is NRZI, NRZI(*YES)

must be specified for the CRTLINSDLC
command.

v If the RIPSS response is NRZ, NRZI(*NO) must

be specified for the CRTLINSDLC command.

SSCP identifier

SSCPID

HST Server Data

SSCP Name

For SDLC connections, if used, the value specified
by the RIPSS configuration must match the last 10
digits of the SSCPID parameter specified on the
CRTCTLRTL command.

Station address

STNADR

SDLC Server Data

Poll address (hex)

For SDLC connections, values specified for the
AS/400 CRTCTLRTL command and the RIPSS
configuration must match.

Examples: Connecting AS/400 to a 4690 retail controller

AS/400 retail communications provide the ability to attach retail controllers to the AS/400 system. Retail
communications manage data with the intersystem communications function (ICF) file. For communications
to begin between programs, the retail communications device must first be configured and varied on.

Example 1: AS/400 to 4690 LU0 connection over token-ring network

Chapter 7. Communicating with remote workstation controllers

75
