AS/400
Prompt
AS/400
Parameter
3684
Definition
Statement 3684 Parameter
Exchange
identifier EXCHID QVSFGLNK SENDID
3684 SENDID parameter must match the last 5 digits of the
EXCHID parameter specified on the AS/400 CRTCTLRTL
command.
RECVID
3684 RECVID parameter must match the last 5 digits of the
EXCHID parameter specified on the AS/400 CRTLINSDLC
command. (This parameter is used only for switched line
communications.)
Modem data
rate MODEMRATE QFSFGLNK LINECON
Value specified for the AS/400 MODEMRATE parameter on the
CRTLINSDLC command must match the value specified for bit 5
of the 3684 LINECON parameter.
NRZI data
encoding NRZI QFSFGLNK LINECON
Value specified for the AS/400 NRZI parameter on the
CRTLINSDLC command must match the value specified for bit 1
of the 3684 LINECON parameter.
Switched
network backup SNBU QFSFGLNK LINECON
Value specified for the AS/400 SNBU parameter on the
CRTLINSDLC command must match the value specified for bit 4
of the 3684 LINECON parameter.
SSCP identifier SSCPID QVSFGLNK SSCPID
3684 SSCPID parameter must match the SSCPID parameter
specified on the AS/400 CRTCTLRTL command.
Station address STNADR QVSFGLNK POLCHAR
3684 POLCHAR parameter must match the 2-digit hexadecimal
address specified for the STNADR parameter on the AS/400
CRTCTLRTL command. Allowed values are in the range 01
through FE.
Switched
connection SWITCHED QFSFGLNK LINECON
Value specified for the AS/400 SWITCHED parameter on the
CRTCTLRTL command must match the values specified for bits
2 and 3 of the 3684 LINECON parameter.
Note: For the AS/400 system, the 3684 QVSFGLNK, QVSFCOMM, and QVSFSESN definitions must each specify
DATALNK=SDLC.
Values specified for the AS/400 parameters on the CRTCTLRTL and CRTLINSDLC commands must match the
values specified on the 3684 LINECON parameter.
Specifying the LINECON parameter for 3684 retail controllers
The following table describes how to coordinate values that are specified for parameters on the AS/400
CRTLINSDLC and CRTCTLRTL commands. You must coordinate the values with bits that are specified for
the 3684 LINECON parameter.
The LINECON parameter is specified as a series of 8 bits, designated
0 through 7 (01234567). The default
value for the LINECON parameter when used with an SDLC line is 01000001, or hex 41.
Chapter 7. Communicating with remote workstation controllers 71
