AS/400

Prompt

AS/400

Parameter

3174

Configuration

Questions

Notes

Local adapter
address

ADPTADR

107

Token-Ring Network Address of the Gateway

If the AS/400 system uses a Token-Ring network line to
connect to the 3174 controller, values specified for question
107 and for the ADPTADR parameter on the CRTLINTRN
command must match.

If the AS/400 system uses an Ethernet line through an 8209
LAN Bridge, see

″Appendix C: Local Area Network

Addressing Considerations

″ in the Communications

Configuration book, for information about specifying the
ADPTADR parameter on the CRTLINETH command.

Connection
number

CNNNBR

423

Host DTE Address (HNAD)

For X.25 lines, the numbers specified on the CRTLINX25
command and in question 423 must match.

368

X.21 Switched Short-Hold Mode Dial Number

For X.21 short-hold mode connections, the numbers
specified on the CRTCTLRWS command and in question
368 must match.

424

3174 DTE Address

For X.25 SVCs, the connection number specified on the
CRTCTLRWS command and in question 424 must match.

Destination
service access
point

DSAP

940

Ring Address Assignment

The value specified for the DSAP parameter on the
CRTCTLRWS command must match the SAP@ specified for
the 3174 on the Ring Address Assignment display. Used for
token-ring only.

Exchange
identifier

EXCHID

215

Physical Unit Identification

For switched connections, the 5-digit hexadecimal value
specified for question 215 must match the last 5 digits of the
exchange identifier specified on the CRTCTLRWS
command.

Link type

LINKTYPE

101

Host Attachment (3174)

Values specified on the CRTCTLRWS command and for
question 101 must match as follows:
v LINKTYPE(*SDLC), 101 = 2
v LINKTYPE(*X25), 101 = 3
v LINKTYPE(*LAN), 101 = 7 (token ring)
v LINKTYPE(*LAN), 101 = 8 (Ethernet)

Modem data
rate select

MODEMRATE

318

Full- or Half-Speed Transmission

The values specified for the MODEMRATE parameter on the
CRTLINSDLC and CRTLINX25 commands must match
question 318 as follows:
v If MODEMRATE(*FULL), 318 = 0
v If MODEMRATE(*HALF), 318 = 1

Chapter 7. Communicating with remote workstation controllers

59
