66 Datasheet
Pinout Specifications
GND GND AD21 IN
BPM0# BPM0# AD22 IN/OUT
GND GND AD23 IN
BPM4# BPM4# AD24 IN/OUT
GND GND AD25 IN
GND GND AE02 IN
TERMB FSBT2 AE03
ID6# IDA6#/IDB6# AE05 IN
RS0# RS0# AE07 IN
REQ0# REQA0#/LEN0# AE09 IN/OUT
REQ3# ASZ0#/DSZ0# AE11 IN/OUT
SBSY# SBSY# AE13 IN/OUT
LOCK# LOCK# AE15 IN/OUT
N/C AE17
BPRI# BPRI# AE19 IN
TRST# TRST# AE21 IN
BPM2# BPM2# AE23 IN/OUT
GND GND AE24 IN
PMI# PMI# AE25 IN
GND GND AF01 IN
TERM FSBT AF02 IN
OUTEN OUTEN AF04 IN Power pod signal
GND GND AF05 IN
RSP# RSP# AF06 IN
GND GND AF07 IN
INIT# INIT# AF08 IN
GND GND AF09 IN
REQ1# WSNP#, D/C#/LEN1# AF10 IN/OUT
GND GND AF11 IN
REQ4# ASZ1#/DSZ1# AF12 IN/OUT
GND GND AF13 IN
TRDY# TRDY# AF14 IN
GND GND AF15 IN
BR0# BREQ0# AF16 IN/OUT
GND GND AF17 IN
BR3# BREQ3# AF18 IN
GND GND AF19 IN
PPODGD# PPODGD# AF20 OUT Power pod signal
GND GND AF21 IN
LINT0 INT AF22 IN
LINT1 NMI AF24 IN
Table 3-2. Pin/Signal Information Sorted by Pin Location (Sheet 14 of 15)
Pin Name
System Bus
Signal Name
Pin
Location
Input/Output Notes
