Datasheet 59
Pinout Specifications
D053# D53# L09 IN/OUT
D056# D56# L11 IN/OUT
VCTERM VCTERM L12 IN
D052# D52# L13 IN/OUT
D081# D81# L15 IN/OUT
VCTERM VCTERM L16 IN
D088# D88# L17 IN/OUT
D082# D82# L19 IN/OUT
VCTERM VCTERM L20 IN
D112# D112# L21 IN/OUT
D116# D116# L23 IN/OUT
VCTERM VCTERM L24 IN
D113# D113# L25 IN/OUT
GND GND M01 IN
D020# D20# M02 IN/OUT
GND GND M03 IN
STBP1# STBP1# M04 IN/OUT
GND GND M05 IN
D028# D28# M06 IN/OUT
GND GND M07 IN
D048# D48# M08 IN/OUT
GND GND M09 IN
STBP3# STBP3# M10 IN/OUT
GND GND M11 IN
D051# D51# M12 IN/OUT
GND GND M13 IN
D084# D84# M14 IN/OUT
GND GND M15 IN
STBP5# STBP5# M16 IN/OUT
GND GND M17 IN
D086# D86# M18 IN/OUT
GND GND M19 IN
D118# D118# M20 IN/OUT
GND GND M21 IN
STBP7# STBP7# M22 IN/OUT
GND GND M23 IN
D115# D115# M24 IN/OUT
GND GND M25 IN
VCTERM VCTERM N02 IN
D023# D23# N03 IN/OUT
GND GND N04 IN
Table 3-2. Pin/Signal Information Sorted by Pin Location (Sheet 7 of 15)
Pin Name
System Bus
Signal Name
Pin
Location
Input/Output Notes
