44 Datasheet
Pinout Specifications
GND GND AB19 IN
GND GND AB21 IN
GND GND AB23 IN
GND GND AB25 IN
GND GND AC02 IN
GND GND AC24 IN
GND GND AD01 IN
GND GND AD03 IN
GND GND AD05 IN
GND GND AD07 IN
GND GND AD09 IN
GND GND AD11 IN
GND GND AD13 IN
GND GND AD15 IN
GND GND AD17 IN
GND GND AD19 IN
GND GND AD21 IN
GND GND AD23 IN
GND GND AD25 IN
GND GND AE02 IN
GND GND AE24 IN
GND GND AF01 IN
GND GND AF05 IN
GND GND AF07 IN
GND GND AF09 IN
GND GND AF11 IN
GND GND AF13 IN
GND GND AF15 IN
GND GND AF17 IN
GND GND AF19 IN
GND GND AF21 IN
GND GND AG02 IN
GND GND AG04 IN
GND GND AG06 IN
GND GND AG08 IN
GND GND AG10 IN
GND GND AG12 IN
GND GND AG14 IN
GND GND AG16 IN
GND GND AG18 IN
GND GND AG20 IN
Table 3-1. Pin/Signal Information Sorted by Pin Name (Sheet 7 of 15)
Pin Name
System Bus
Signal Name
Pin
Location
Input/Output Notes
