Datasheet 43
Pinout Specifications
DEP01# DEP1# J05 IN/OUT
DEP02# DEP2# T06 IN/OUT
DEP03# DEP3# T04 IN/OUT
DEP04# DEP4# J09 IN/OUT
DEP05# DEP5# J11 IN/OUT
DEP06# DEP6# T08 IN/OUT
DEP07# DEP7# T10 IN/OUT
DEP08# DEP8# J19 IN/OUT
DEP09# DEP9# J17 IN/OUT
DEP10# DEP10# T18 IN/OUT
DEP11# DEP11# T16 IN/OUT
DEP12# DEP12# J21 IN/OUT
DEP13# DEP13# J23 IN/OUT
DEP14# DEP14# T20 IN/OUT
DEP15# DEP15# T22 IN/OUT
DRDY# DRDY# AC11 IN/OUT
DRDY0# DRDY_C1# AA07 OUT
DRDY1# DRDY_C2# AA21 OUT
FERR# FERR# AH25 OUT
GND GND A01 IN
GND GND A03 IN
GND GND A05 IN
GND GND A08 IN
GND GND A13 IN
GND GND A16 IN
GND GND A19 IN
GND GND A20 IN
GND GND A23 IN
GND GND A24 IN
GND GND AA02 IN
GND GND AA20 IN
GND GND AA24 IN
GND GND AB01 IN
GND GND AB03 IN
GND GND AB05 IN
GND GND AB07 IN
GND GND AB09 IN
GND GND AB11 IN
GND GND AB13 IN
GND GND AB15 IN
GND GND AB17 IN
Table 3-1. Pin/Signal Information Sorted by Pin Name (Sheet 6 of 15)
Pin Name
System Bus
Signal Name
Pin
Location
Input/Output Notes
