Datasheet 63
Pinout Specifications
GND GND V15 IN
A038# AA38#/AB38# V16 IN/OUT
GND GND V17 IN
A029# AA29#/xTPRValue2# V18 IN/OUT
GND GND V19 IN
A045# AA45#/AB45# V20 IN/OUT
GND GND V21 IN
A047# AA47#/AB47# V22 IN/OUT
GND GND V23 IN
A040# AA40#/AB40# V24 IN/OUT
GND GND V25 IN
GND GND W02 IN
A006# AA06#/EXF3# W03 IN/OUT
A012# AA12#/BE4# W05 IN/OUT
A014# AA14#/BE6# W07 IN/OUT
A021# AA21#/DID5# W09 IN/OUT
A026# AA26#/AB26# W11 IN/OUT
A022# AA22#/DID6# W13 IN/OUT
A037# AA37#/AB37# W15 IN/OUT
A032# AA32#/ATTR0# W17 IN/OUT
A030# AA30#/xTPRValue3# W19 IN/OUT
A044# AA44#/AB44# W21 IN/OUT
A046# AA46#/AB46# W23 IN/OUT
A041# AA41#/AB41# W25 IN/OUT
GND GND Y01 IN
A007# AA07#/EXF4# Y02 IN/OUT
GND GND Y03 IN
A013# AA13#/BE5# Y04 IN/OUT
GND GND Y05 IN
A008# AA08#/BE0# Y06 IN/OUT
GND GND Y07 IN
A017# AA17#/DID1# Y08 IN/OUT
GND GND Y09 IN
A024# AA24#/DID8# Y10 IN/OUT
GND GND Y11 IN
A025# AA25#/DID9# Y12 IN/OUT
GND GND Y13 IN
A034# AA34#/ATTR2# Y14 IN/OUT
GND GND Y15 IN
A036# AA36#/AB36# Y16 IN/OUT
GND GND Y17 IN
Table 3-2. Pin/Signal Information Sorted by Pin Location (Sheet 11 of 15)
Pin Name
System Bus
Signal Name
Pin
Location
Input/Output Notes
