Installation Instructions
Copyright IBM Corp. 1998
Page 15 June 17 1998 EC : F34705 PN : 26L0227
Subnetwork X (ATM address 39.99.99.99.99.99.0.9.77.77)
Subnetwork Y (ATM address 39.99.99.99.99.99.99.0.0.88.88)
NNI vpi0
Cluster 3 (ACN=3)
WS 3
4.3 6.1
HUB d (HN=1)
Figure 2. Example of a network at the ATM firware kit level(MES 5099).
WS 2 WS 1
UNI
SSI NNI
3.1
vpi3 vpi3
4.1 5.1 3.2 2.1
4.3
HUB a (HN=1) HUB b (HN=2) HUB c (HN=1)
Cluster 1 (ACN=1) Cluster 2 (ACN=2)
