Page 14
2.8 SET MINIMUM PNNI PHASE-1 PARAMETERS.
NOTE THAT INTEROPERABILITY BETWEEN V.2.X.X CLUSTERS AND
V.3.X.X PEER-GROUPS IS POSSIBLE THROUGH NNI AND IISP LINK
RESPECTIVELY.
Figure 2, represents a network configured with 8260/8285 at the ATM firmware
kit level MES5099. In this example there are two subnetworks (X and Y), three
clusters and four hubs, using UNI/SSI/NNI links. You should recognize in this
drawing the different components of your current network.
Installation Instructions
Copyright IBM Corp. 1998
Page 14
June 17 1998
EC : F34705
PN : 26L0227
