Impex PHE 2000 User Manual
Powerhouse elite, Phe 2000, Model phe 2000

NOTE:
Please read all instructions
carefully before using this
product
Table of Contents
Safety Notice
Hardware Identifier
Assembly Instruction
Parts List
Warranty
Ordering Parts
Model
PHE 2000
Retain This
Manual for
Reference
05-31-04
OWNER'S
MANUAL
POWERHOUSE ELITE
PHE 2000
IMPEX FITNESS PRODUCTS
14777 DON JULIAN RD., CITY OF INDUSTRY, CA 91746
Tel: (800) 999-8899 Fax: (626) 961-9966
Table of contents
Document Outline
- BEFORE YOU BEGIN...................................................................................... 1
- IMPORTANT SAFETY NOTICES..................................................................... 2
- HARDWARE PACK……….....…....................................................................... 3
- ASSEMBLY INSTRUCTIONS........................................................................... 6
- WEIGHT RESISTANCE CHART........................................................................24
- PARTS LIST………………………………………………………………………….. 25
- WARRANTY.................................................................................................… 26
- ORDERING PARTS......................................................................................... 26
- HARDWARE PACK
- HARDWARE PACK
- ASSEMBLY INSTRUCTION
- Attach the Butterfly Base (#14) to the Vertical Frame (#5). Secure it with one 4 ¾” x 2” Bracket (#26), two M10 x 3 ½” Carriage Bolts (#71), two ( ¾” Washers (#87), and two M10 Aircraft Nuts (#89).
- Insert the Right Butterfly (#20) into the right pivot on Butterfly Base. Secure it with one M10 x ¾” Allen Bolt (#76) and (1 3/8” Washer (#66) from the bottom.
- Insert the Butterfly Handle (#13) into the pivot on the Right Butterfly. Secure it with one M10 x ¾” Allen Bolt (#76) and ( 1 3/8” Washer (#66).
- Repeat Procedures B and C above to install the other side.
- DIAGRAM 6
- Station
- Leg Developer
- Station
- Leg Developer
