Appendix B: Sensor Tables Intel
®
Server Board S5000PAL / S5000XAL TPS
Revision 1.4
Intel order number: D31979-007
92
Sensor
Name
Sensor
Number
System
Applica-
bility
Sensor Type Event /
Reading
Type
Event Offset
Triggers
Criticality Assert /
De-assert
Readable
Value /
Offsets
Event Data Rearm Standby
Non-red:
insufficient Critical
Redun degrade
from full
Redun degrade
from non-
redundant OK
Presence OK
Failure Critical
Predictive fail
Non-Critical
A/C lost Critical
Power
Supply
Status 1 70h Chassis-
specific
Power Supply
08h Sensor
Specific
6Fh
Configuration
error Non-Critical
As and De – Trig Offset A X
Presence OK
Failure Critical
Predictive fail
Non-Critical
A/C lost Critical
Power
Supply
Status 2 71h Chassis-
specific
Power Supply
08h Sensor
Specific
6Fh
Configuration
error Non-Critical
As and De – Trig Offset A X
Power
Nozzle
Power
Supply 1 78h Chassis-
specific
Current
03h Threshold
01h [u] [c,nc] Threshold
defined As and De Analog R, T A –
Power
Nozzle
Power
Supply 2 79h Chassis-
specific
Current
03h Threshold
01h [u] [c,nc] Threshold
defined As and De Analog R, T A –
Power
Gauge
V1 rail
(+12v)
Power
Supply 1 7Ah Chassis-
specific
Current
03h Threshold
01h [u] [c,nc] Threshold
defined As and De Analog R, T A –
