Appendix E: Supported Intel
®
Server Chassis Intel
®
Server Board S5000PAL / S5000XAL TPS
Revision 1.4
Intel order number: D31979-007
110
TP02094
A
B
D
C
E
F
G
H
I
A
L
K
J
M
N
A. Rack Handles H. CPU Air Duct
B. SAS/SATA Backplane I. System Fan Assembly
C. Air Baffles J. Standard Control Panel
D. Power Distribution Module K. Flex Bay – 6 th HDD or Tape (Optional)
E.
1+1 750 Watt Power Supply
Modules
L. Five SATA/SAS Hard Drive Bays
F. Riser Card Assembly M. Slim-Line Optical Drive Bay
G. System Memory N. Front Bezel (Optional)
Mid-pane – Passive SAS/SATA
or Active SAS/SAS RAID
(Not shown)
Figure 31. 2U – Intel
®
Server Chassis SR2500 Overview
