8 Intel ISP1100 Internet Server Product Guide
Server Board Features
Table 1 summarizes the TR440BX server board features.
Table 1. Server Board Features
Feature Description
Form Factor MicroATX (9.6 inches by 9.6 inches)
Processor Supports an Intel ® Pentium ® III processor or Intel Celeron ™ processor in a
PGA370 socket.
Memory Four 168-pin dual in-line memory module (DIMM) sockets
Support unbuffered and registered SDRAM DIMMs
Supports up to 1 GB of ECC, SPD SDRAM with registered or unbuffered DIMMs
Chipset Intel ® 82440BX AGPset, consists of:
Intel ® 82443BX PCI/AGP controller (PAC)
Intel ® 82371EB PCI ISA IDE Xcelerator (PIIX4E)
I/O Control SMSC FDC37B807 I/O controller
Peripheral Interfaces Two integrated Intel ® Pro/100+ Server (82559) Ethernet controllers
One standard diskette drive interface
One high-density diskette drive interface for slim-line diskette drive
Two IDE interfaces with Ultra DMA/33 support
Two serial ports (1 rear, 1 front)
Two USB ports
Two PS/2 † interfaces for keyboard and mouse
LED panel interface
Expansion One PCI bus in combination with a 2x11 riser sideband connector supports a
passive dual-slot PCI riser card (32 bit/33 MHz)
BIOS Intel ® /AMI BIOS
Intel ® E28F008S585 8-Mbit boot block flash memory
Supports SMBIOS, Advanced Power Management (APM), Advanced
Configuration and Power Interface (ACPI), and Plug and Play
Other Features Speaker
Hardware monitor
Wake on Ring
Wake on LAN †
SCSI LED connector
