Intel 80303 User Manual
Intel

Intel
®
80303 and 80302 I/O
Processors
Specification Update
May 6, 2003
Notice: The Intel
®
80303 and Intel
®
80302 I/O Processors processor may contain design defects
or errors known as errata. Characterized errata that may cause the product’s behavior to deviate
from pubished specifications are documented in this specification update.
Order Number:
273355-010
