Intel 80303 User Manual
Page 22
Documentation Changes
22
Intel
®
80303 and 80302 I/O Processors
Specification Update
"42
(BC_1,
*,
control,
1)," &
"43
(BC_1,
i_rstz,
output3,
X,
111,
1,
Z)," &
"44
(CBSC_1,
GPIO(3),
bidir,
X,
45,
1,
Z)," &
"45
(BC_1,
*,
control,
1)," &
"46
(CBSC_1,
GPIO(4),
bidir,
X,
47,
1,
Z)," &
"47
(BC_1,
*,
control,
1)," &
"48
(CBSC_1,
GPIO(5),
bidir,
X,
49,
1,
Z)," &
"49
(BC_1,
*,
control,
1)," &
"50
(CBSC_1,
GPIO(6),
bidir,
X,
51,
1,
Z)," &
"51
(BC_1,
*,
control,
1)," &
"52
(CBSC_1,
GPIO(7),
bidir,
X,
53,
1,
Z)," &
"53
(BC_1,
*,
control,
1)," &
"54
(BC_4,
irqz(0),
input,
X)," &
"55
(BC_4,
irqz(1),
input,
X)," &
"56
(BC_4,
irqz(2),
input,
X)," &
"57
(BC_4,
irqz(3),
input,
X)," &
"58
(BC_4,
irqz(4),
input,
X)," &
"59
(BC_4,
irqz(5),
input,
X)," &
"60
(BC_1,
nc2,
output3,
X,
65,
1,
Z)," &
"61
(BC_4,
lcdinitz,
input,
X)," &
"62
(BC_4,
logic1,
input,
X)," &
"63
(BC_1,
failz,
output3,
X,
110,
1,
Z)," &
"64
(BC_4,
nmiz,
input,
X)," &
"65
(BC_1,
*,
control,
1)," &
"66
(BC_4,
nc3,
input,
X)," &
"67
(BC_4,
nc4,
input,
X)," &
"68
(BC_4,
nc5,
input,
X)," &
"69
(BC_4,
nc6,
input,
X)," &
"70
(BC_4,
nc7,
input,
X)," &
"71
(BC_4,
nc8,
input,
X)," &
"72
(BC_4,
nc9,
input,
X)," &
"73
(BC_4,
nc10,
input,
X)," &
"74
(BC_4,
nc11,
input,
X)," &
"75
(BC_4,
nc12,
input,
X)," &
"76
(BC_4,
nc20,
input,
X)," &
"77
(BC_4,
nc13,
input,
X)," &
"78
(BC_4,
nc15,
input,
X)," &
"79
(BC_4,
nc14,
input,
X)," &
"80
(BC_4,
nc16,
input,
X)," &
"81
(BC_4,
pwrdelay,
input,
X)," &
"82
(BC_1,
nc17,
output3,
X,
65,
1,
Z)," &
"83
(BC_1,
nc19,
output3,
X,
65,
1,
Z)," &
"84
(BC_1,
nc18,
output3,
X,
85,
1,
Z)," &
"85
(BC_1,
*,
control,
1)," &
"86
(BC_1,
dclk(3),
output3,
X,
111,
1,
Z)," &
"87
(BC_1,
dclk(2),
output3,
X,
111,
1,
Z)," &
"88
(BC_1,
dclk(1),
output3,
X,
111,
1,
Z)," &
Table 24-4.
Intel
®
80303 I/O Processor Boundary Scan Register Bit Order (Sheet 2 of 10)
#
Cell Type
Name
Function Safe bit
Control Signal
Disable Value
Disable Result
