80303 and 80302 I/O Processors
Specification Update
"230
(CBSC_1,
s_ad(56),
bidir,
X,
322,
0,
Z)," &
"231
(CBSC_1,
s_ad(57),
bidir,
X,
322,
0,
Z)," &
"232
(CBSC_1,
s_ad(55),
bidir,
X,
322,
0,
Z)," &
"233
(CBSC_1,
s_ad(60),
bidir,
X,
322,
0,
Z)," &
"234
(CBSC_1,
s_ad(59),
bidir,
X,
322,
0,
Z)," &
"235
(CBSC_1,
s_ad(62),
bidir,
X,
322,
0,
Z)," &
"236
(CBSC_1,
s_ad(61),
bidir,
X,
322,
0,
Z)," &
"237
(CBSC_1,
s_cbez(5), bidir,
X,
331,
0,
Z)," &
"238
(CBSC_1,
s_par64,
bidir,
X,
239,
0,
Z)," &
"239
(BC_1,
*,
control,
0)," &
"240
(CBSC_1,
s_cbez(4), bidir,
X,
331,
0,
Z)," &
"241
(CBSC_1,
s_req64z,
bidir,
X,
242,
0,
Z)," &
"242
(BC_1,
*,
control,
0)," &
"243
(CBSC_1,
s_ad(63),
bidir,
X,
322,
0,
Z)," &
"244
(CBSC_1,
s_cbez(7), bidir,
X,
331,
0,
Z)," &
"245
(CBSC_1,
s_ack64z,
bidir,
X,
246,
0,
Z)," &
"246
(BC_1,
*,
control,
0)," &
"247
(CBSC_1,
s_ad(0),
bidir,
X,
329,
0,
Z)," &
"248
(CBSC_1,
s_ad(2),
bidir,
X,
329,
0,
Z)," &
"249
(CBSC_1,
s_cbez(6), bidir,
X,
331,
0,
Z)," &
"250
(CBSC_1,
s_ad(8),
bidir,
X,
328,
0,
Z)," &
"251
(CBSC_1,
s_ad(3),
bidir,
X,
329,
0,
Z)," &
"252
(CBSC_1,
s_ad(4),
bidir,
X,
329,
0,
Z)," &
"253
(CBSC_1,
s_ad(7),
bidir,
X,
329,
0,
Z)," &
"254
(CBSC_1,
s_ad(1),
bidir,
X,
329,
0,
Z)," &
"255
(CBSC_1,
s_cbez(0), bidir,
X,
330,
0,
Z)," &
"256
(CBSC_1,
s_ad(5),
bidir,
X,
329,
0,
Z)," &
"257
(CBSC_1,
s_ad(6),
bidir,
X,
328,
0,
Z)," &
"258
(CBSC_1,
s_ad(10),
bidir,
X,
328,
0,
Z)," &
"259
(BC_4,
s_m66en,
input,
X)," &
"260
(CBSC_1,
s_ad(12),
bidir,
X,
328,
0,
Z)," &
"261
(CBSC_1,
s_ad(11),
bidir,
X,
328,
0,
Z)," &
"262
(CBSC_1,
s_ad(9),
bidir,
X,
329,
0,
Z)," &
"263
(CBSC_1,
s_ad(14),
bidir,
X,
328,
0,
Z)," &
"264
(CBSC_1,
s_serrz,
bidir,
X,
265,
0,
Z)," &
"265
(BC_1,
*,
control,
0)," &
"266
(CBSC_1,
s_ad(15),
bidir,
X,
328,
0,
Z)," &
"267
(CBSC_1,
s_cbez(1), bidir,
X,
330,
0,
Z)," &
"268
(CBSC_1,
s_ad(13),
bidir,
X,
328,
0,
Z)," &
"269
(CBSC_1,
s_par,
bidir,
X,
270,
0,
Z)," &
"270
(BC_1,
*,
control,
0)," &
"271
(CBSC_1,
s_stopz,
bidir,
X,
280,
0,
Z)," &
"272
(CBSC_1,
s_perrz,
bidir,
X,
273,
0,
Z)," &
"273
(BC_1,
*,
control,
0)," &
"274
(CBSC_1,
s_lockz,
bidir,
X,
275,
0,
Z)," &
"275
(BC_1,
*,
control,
0)," &
"276
(CBSC_1,
s_trdyz,
bidir,
X,
280,
0,
Z)," &
Table 24-4.
Intel
®
80303 I/O Processor Boundary Scan Register Bit Order (Sheet 6 of 10)
#
Cell Type
Name
Function Safe bit
Control Signal
Disable Value
Disable Result
