Documentation Changes
18 Intel ® 80303 and 80302 I/O Processors Specification Update
3. Figure 13-22 on pg 13-40 did not print correctly
Problem: Figure 13-22 on pg 13-40 did not print correctly.
Workaround: Replace Figure 13-22 with the following:
Affected Docs: Intel
®
80303 I/O Processor Developer’s Manual.
4. Figure 13-18, pg 13-35
Problem: Replace Figure 13-18 with the following:
Affected Docs: Intel
®
80303 I/O Processor Developer’s Manual.
A6814-01
PULLCKE = 0 PULLCKE = 1
SCKE out
P_RST#
A4662-02
SDRAM
DIMM0
DQ(71:0)
I_CLK
P_CLK
DCLKin
DQ(71:0)
DCLKout
SDQ(71:0) SDQ(71:0)
CLK(3:0) CLK(3:0)
SDRAM
DIMM1
