GA-N680SLI-DQ6 Motherboard - 54 -
English
2-7 MB Intelligent Tweaker(M.I.T.)
CMOS Setup Utility-Copyright (C) 1984-2007 Award Software
MB Intelligent Tweaker(M.I.T.)
System Clock Setting [Press Enter]
Robust Graphics Booster [Auto]
CPU Clock Ratio (Note) [16X]
******** System Voltage Optimized ********
System Voltage Control [Manual]
DDR2 Voltage Control [Normal]
NB/PCIE Voltage [Normal]
SB/PCIE Voltage [Normal]
FSB Voltage Control [Normal]
HT-Link Voltage [Normal]
SB Standby Voltage [Normal]
CPU Voltage Control [Normal]
Normal CPU Vcore 1.40000V
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level
Incorrectly using these features may result in system instability or corruption.
Doing a overclock or overvoltage on CPU, chipsets and memory modules may result in
damages or shortened life expectancy to these components.
Please be aware that the M.I.T. menu items are for power users only.
(Note) This item will show up when you install a processor that supports this function.
System Clock Setting
CMOS Setup Utility-Copyright (C) 1984-2007 Award Software
System Clock Setting
SLI-Ready Memory [Disable] Disable
FSB-Memory Clock Mode [Auto]
x FSB-Memory Ratio Auto
x CPU Host Frequency (Mhz) Auto 133.3
Actual CPU Clock (Mhz) 133.3
x Memory Frequency (Mhz) Auto 800.0
Actual Memory Clock (Mhz) 800.0
PCIE x16 Slot 1 Clock (Mhz) [Auto] 100
PCIE x8 Clock (Mhz) [Auto] 100
PCIE x16 Slot 2 Clock (Mhz) [Auto] 100
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level
