Page 55
Troubleshooting and Problem Solving
40
IBM System Storage DCS9550 1S1 Storage Expansion Unit Installation, Service, and User Guide
Table 4–2 Ops Panel LED States
LED
Definition
Color
Normal
Status
Fault
Status
Invalid
Address
Indicates that an invalid
Enclosure ID has been selected
or that the selection has
changed after Power On
Amber Off
Flashing
Power On
Enclosure Powered On
Green
On
Off
System Fault
System/SCM Fault
Amber Off
On
PSU/Cooling
Fault
PSU Cooling fault or enclosure
over-temperature.
Amber Off
On
2Gb Link
Speed
Indicates link speed
Green
Off
On
Hub Mode
Not Used
Green
Off
Off
