3.1.1
Power Supply/Cooling Module LEDs
The Power Supply/Cooling module incorporates 4 LEDs, located below the On/Off switch and
• Under Normal conditions the LEDs should all be illuminated constant GREEN
• If a problem is detected the color of the relevant LED will change to AMBER.
Table 3–1
PSU LEDs
AC PSU
PSU Good
Green
AC input Fail Amber
Fan Fault
Amber
DC Output
Fail
Amber
